SCAG AERSTORM AERATOR 30″ TINE WIDTH

AerStorm Models   Model Description AS30-23CV Stand-On Aerator, 30″ Tine Width – Kohler® Command PRO® 23 HP AS30-23CV-DS Stand-On Aerator with Drop Seeder, 30″ Tine Width – Kohler® Command PRO® 23 HP   Aerator Specifications   Specification AerStorm ENGINE SPECIFICATION General Type Heavy-duty industrial/commercial Brand Kohler Command Pro Model CV732 Horsepower 23.5 HP @ 3600 RPM Torque 40.3 ft-lbs. (peak) Type 4 cycle gas, twin-cylinder, air-cooled, OHV, vertical shaft engine Displacement 747 cc (45.6 cubic inch) Cylinders 2 cast-iron sleeves Governor Mechanical type governor with variable speed control set at 3600 rpm (±100 rpm), idle set at 1800 rpm (±150 rpm) Air Intake Group Large capacity 2-stage canister air filter Exhaust Group Single. exhaust canister muffler Fuel Pump Group Integral fuel pump with inline fuel filter, internal fuel line vent; float feed; two barrel, adjustable idle, afterfire solenoid. Oil Pump Group Full pressure lube, with full-flow filter, 2 quart oil capacity Starter/Electrical/Charging System “12 volt “”maintenance-free”” sealed battery with alternator, solid state ignition with key start. 15 amp charging system, regulated.” ENGINE DECK Thickness 1/4″ steel Fuel Tank 5.5 gallon (20.8 liters) tank with molded-in cup holder Drive Wheels/Tires 18 x 6.5 – 8 four-ply pneumatic tubeless, radius edge Brakes Lever actuated linkage to brakes on both drive wheels Operator Platform Heavy gauge steel with extruded star pattern for no-slip footing. Dual adjustable suspension for operator comfort level preference. Operator Comfort Pad Large heavily-bolstered operator cushion can be easily removed without tools for access to hydraulics DRIVE SYSTEM Type Hydro drive with two variable displacement pumps and two cast-iron high-torque wheel motors for independent control of each drive wheel Hydro Pumps Two Hydro-Gear PG Series 10cc pumps with dump valves for movement without running engine; one cooling fan Drive Wheel Motors Two Parker TG 14.5 cu. inch cast-iron high torque wheel motors Hydro Fluid Cooling Group 3.0 qt. capacity cooling reservoir; uses SAE 20W50 fluid and 10 micron filter Steering/Travel Control Twin lever steering control with individual control to each wheel Dump Valves Allows for movement without engine running Axles 1.25″ heavy-duty, straight motor shafts Wire Harness 14 and 16 gauge wire Safety Group Footplate-actuated operator presence system interlock to engine killFootplate-actuated operator presence system interlock to engine kill Forward Speed Range 0 up to 7.0 mph Reverse Speed Range 0 up to 3.0 mph PRODUCT SPECIFICATION Type Plug-style aeration. Mid/under-belly mount. Aerating Width 30″ Aerating Depth/Adjustment 1” to 4” in 1/2” increments. Simple and intuitive depth selection pin with easy-grip rubber knob. Tines 48 self-cleaning, replaceable, steel coring tines Tine Activation & Pressure Hydraulic tine engagement (raise and lower) via a foot-activated switch. Tine activation switch on the instrument panel prevents accidental engagement/disengagement while working or transporting. Adjustable hydraulic down-pressure helps to penetrate even the hardest and driest soils to ensure effective aeration performance in all conditions.   Product Specifications   PRODUCT SPECIFICATION AerStorm LENGTH 68.6″ WIDTH 49.8″ HEIGHT 51.2″   **Specifications subject to change without notice. Actual ground speeds may vary. Accessories subject to availability.
